USB Interface Flatbed Inkjet Screen Engraver Machine 360/508/720dpi Resolution

USB Interface Flatbed Inkjet Screen Engraver Machine 360/508/720dpi Resolution

MOQ: 1 set
Standard Packaging: Wooden case
Delivery Period: 30 days
Payment Method: T/T
Supply Capacity: 10 sets
Detail Information
Place of Origin
china
Brand Name
DOSUN
Certification
ISO9000
Model Number
1500mmx2600mm(customized)
Model:
BF X*Y
Resolution:
360/508/720dpi
Interface:
USB
Power:
1.5kw/220v, 50HZ
Acceptable File Format:
Tiff
Light Source:
Laser Diode
Minimum Order Quantity:
1 set
Packaging Details:
Wooden case
Delivery Time:
30 days
Payment Terms:
T/T
Supply Ability:
10 sets
Highlight:

rotary engravers

,

rotary engraving machine

,

508dpi flatbed inkjet screen engraver

Product Description





USB Interface Flatbed Inkjet Screen Engraver Machine 360/508/720dpi Resolution



DOSUN BLUE-ROTARY UV Laser Engraver is a new generation of CTS (computer to screen) equipment. By using DOSUN UV-FINATM Laser Engine, it can directly image on the sensitive layer.

By using UV-FINATM Laser Engine technology, sensitive emulsion, engraving technology is basically same with the traditional technology, improving the precision and efficiency.



Feature:



  • Using advanced high-power UV laser and fiber dot-matrix, BLUE-ROTARY UV Laser Engraver is the fastest in engraving industry.
  • UV laser engraving is a low carbon, environment protection technology.
  • No consumable items: Do not need film, ink, wax
  • UV laser engraving is a “friendly” engraving technology.The manufacture process is not only as same as traditional process, but also more convenient. Basing on the design principle of “convenient, practical, reliable, advanced”, in the process of engraving image, the equipment provides monitor display, operation help and so on. By using the software and hardware, it all can reflect a “friendly” attitude to operational workers.

Specification

Model BR2500 BR3000 BR3500
Screen Breadth 2500mm 3000mm 3500mm

Screen Repeat 640mm(standard)

820mm/914mm/1018mm(optional)

Resolution 360/720dpi (300/600dpi;254/508dpi customizable)
Registration Accuracy ±0.02mm
Imaging Light Source 405nm laser diode LD
Engraving Speed 6~8min./m(640mm)
Acceptable File Format BMP/TIFF
Interface USB
Power 1.5KW/220V, 50Hz

Dimension 3950mm×750mm×1220mm(BR2500)

4450mm×750mm×1220mm(BR3000)

4950mm×750mm×1220mm(BR3500)

Net Weight 1000kg(BR2500) 1100kg(BR3000)

1 200kg (BR3500)



Process

Wash screen→ Mixing glue→ reshaping→ coating→ Low temperature baking→ laser Engraving→ Developing→ Retouching screen→ High temperature baking



Compare to other brand

Compare to Image and any other brand in China

  • The whole machine including software, Dosun developed by ourselves. No need any other support. (image change the software from some other company , you will find it is difficult to operate, and dosun is very easy)
  • Service team, we have mature service team in China. Also our local service support from Agent. Any time you meet problem, we reach to you in time.
  • Use of high-precision rack transmitting design, fast return back to the start bit after finish engraving. Easy erection, unlimited screen length.
  • Lens which developed by Academic Divisions of the Chinese Academy sciences. Balancing guild rail, make sure from 400mm t- 2500mm, totally automatic adjust. And mistake between 1 to100mm. (As we know, Image cannot print two dot. Their software will bigger the dot when print out. So such kind of fine designs they cannot print well)
  • Tailstock with manual and electric, default electric.
  • And all the important parts we use famous brand in the world, if such low price, they must just use Chinese local brand.
  • Repeat choice between 400mm to 2500mm, integrate all in one. With lens safe anti-collision system, intelligently identify current repeat, make sure proper printing.
  • Adopting parallel guide rail, professional assembly measurement and control, ensure straightness tolerance of rail within 20um, and ensure high imaging quality.
  • Rotate servo motor or general asynchronism motor, wide speed range, test with thermal pater.
  • Water cooling and semiconductor cooling system, optional.
  • 360,720,1440,508,1016 dpi, optional.
  • Paths of diode 16,24,32 optional.
  • High precision encoder from Japan.
